Model S7000 Series
Egress-ready and space-smart. The S7000 Series side-sliding fire doors offer seamless fire protection with a slim head track and a compact pocket design—perfect for tight spaces and sleek openings.
FIRE
RATED
90 MIN FIRE RATED UNDER UL10B
SMOKE RATED
SMOKE AND DRAFT RATED UNDER UL1784
OVERHEAD COILING
COIL BOX ABOVE OPENING
NO
EGRESS
NOT AVAILABLE WITH EGRESS
Get straight to the details. Everything you need all in one click.
Resource Hub
Built for tight spaces.
Designed for open minds.


Freedom to design. Open without limits.
Side sliding fire doors offer the perfect alternative to traditional fire doors where head room is limited. Egress doors can be provided anywhere along the opening as needed.


The details that matter.
Ratings
- 1-3 hr UL10B
- 1784 UL Smoke & Draft Labeled
Egress
Single or multiple fixed complying egress doors available when required
Radius
- Negotiates 3'-0" curve with egress doors
- 1'-6" without without egress
Available Sizes
- Widths to 80'-0"
- Bi-parting 160'-0"
- Heights to 24'-0"
- For Larger sizes and custom configurations consult the factory
Finishes
- McKEON Sterling Grey
- RAL Powder Coat
- Stainless Steel
Operation
- Electric Motor
- Manual Options Available
- Fail safe design - automatic self closing mechanism does not require power operation to self-close
Download our specs.
Specification Key
-G = McKeon Sterling Grey (one color option)
-PC = Powder Coat, 188 color selection from standard colors (download chart here)
-SS = Stainless Steel, No. 4 polish finish
RAL Powder Coat Chart
Explore our RAL 49 Series Series Color Chart, featuring a wide range of standard colors in durable powder coat finishes. For projects requiring specific color matching, custom colors and finishes beyond this chart are also available upon request.
Download our details.
Download individual PDF sheets, CADs and more BELOW.
Download it all.
S7600 Spec Kit

Need more details? Click below to download individual product PDF sheets and get all the details you need at your fingertips.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Seamlessly integrate our product into your plans. Click below to download CAD files for precise design compatibility.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Access detailed product specifications. Download a Word document template tailored to the finishes listed above for seamless project planniang.
- S7600-G (McKeon Sterling Grey)
- S7600-PC (RAL Powder Coat Selection)
- S7600-SS (Stainless Steel No 4. Polish)

Get all the product data you need to start specifying with confidence. Download comprehensive info in this section to streamline the process.
• S7000 Series Product Cut Sheet
• RAL Color Chart

Access third-party testing reports that verify this product meets all required standards. Download the complete listing report below.
• Listing Report S7000
S7700 Spec Kit

Need more details? Click below to download individual product PDF sheets and get all the details you need at your fingertips.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Seamlessly integrate our product into your plans. Click below to download CAD files for precise design compatibility.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Access detailed product specifications. Download a Word document template tailored to the finishes listed above for seamless project planniang.
- S7700-G (McKeon Sterling Grey)
- S7700-PC (RAL Powder Coat Selection)
- S7700-SS (Stainless Steel No 4. Polish)

Get all the product data you need to start specifying with confidence. Download comprehensive info in this section to streamline the process.
• S7000 Series Product Cut Sheet
• RAL Color Chart

Access third-party testing reports that verify this product meets all required standards. Download the complete listing report below.
• Listing Report S7000
S7900 Spec Kit

Need more details? Click below to download individual product PDF sheets and get all the details you need at your fingertips.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Seamlessly integrate our product into your plans. Click below to download CAD files for precise design compatibility.
- Elevation Detail
- Section Detail
- Plan Detail
- Jamb Details
- Bottom Bar Detail
- Coil Box Sizing Chart

Access detailed product specifications. Download a Word document template tailored to the finishes listed above for seamless project planniang.
- S7900-G (McKeon Sterling Grey)
- S7900-PC (RAL Powder Coat Selection)
- S7900-SS (Stainless Steel No 4. Polish)

Get all the product data you need to start specifying with confidence. Download comprehensive info in this section to streamline the process.
• S7000 Series Product Cut Sheet
• RAL Color Chart

Access third-party testing reports that verify this product meets all required standards. Download the complete listing report below.
• Listing Report S7000
Already know the
S7000 Series product you're looking for?
Manual Options (Available Upon Request):
Model S7200 - Side Acting with No Egress
Model S7400 - Side Acting with (2) Egress Door
Model S7500 -
Side Acting with (2) or more Egress Doors
Motorized Options:
Model S7600 - Side Acting with No Egress
Model S7700 - Side Acting with (2) Egress Door
Model S7900 - Side Acting with (2) or more Egress Doors
